Connect the detection devices directly to the control terminals using the included low-voltage leads. Ensure the positive and negative connections match the polarity markings to prevent signal faults.
Position the devices at a consistent height on either side of the door with a clear line of sight. Any obstruction or uneven mounting can trigger false alerts or prevent the door from closing properly.
Use shielded cable for runs exceeding 20 feet to reduce electrical interference from motors or nearby lighting circuits. Avoid routing cables parallel to high-voltage lines to maintain signal integrity.
Verify alignment by checking the indicator LEDs after power-up. A steady light indicates correct installation, while blinking or dim LEDs require adjustment of the mounting brackets or cable connections.
Sensor Connection Planning and Installation
Mount detection units at equal height on both sides of the entryway with a straight visual path. Misalignment by even a few millimeters can trigger false stops or prevent the door from closing securely.
Use the included low-voltage leads and follow polarity markings precisely. For runs longer than 20 feet, shielded cables are recommended to prevent interference from nearby motors or lighting circuits.
Verify proper alignment by checking LED indicators after powering the system. Steady lights confirm correct setup, while blinking or no light requires bracket adjustment, cable inspection, or slight repositioning of the units for full functionality.
Identify Terminals and Proper Polarity for Installation
Connect the positive lead to the marked terminal on the detection unit and the negative lead to the corresponding ground terminal. Reversing these connections may prevent operation or cause intermittent failures.
Use a multimeter to verify voltage at each terminal before securing the connections. Standard low-voltage systems typically operate between 12 and 24 volts DC, and correct polarity ensures the indicator LEDs function properly.
Label each wire with tape or heat shrink to maintain consistent connections during installation. Confusing leads between multiple units can cause misfires or false triggers in the control logic.
Inspect the terminal screws for corrosion or damage before attaching wires. Loose or oxidized contacts reduce continuity and can result in unreliable activation or permanent malfunction of the detection system.
After all connections are secured, test the setup by temporarily activating the opener. Verify that both indicators respond correctly and that any safety stops or motion detection features engage without delay or error.
